ITW Dynatec DY 2008 - Page 97

ITW Dynatec c. 2003 Appendix C pg. 5
DY2008 Controller Manual #50-14 Revised 8/08
Spike Duration
CHANNEL TIME CHANNEL TIME CHANNEL TIME CHANNEL TIME
Shutter Assignment
TRIGGER: __________
Shutter Dwell Time
_________ SECONDS
Stop Configuration
CHANNE
L
NOT FINSH/
FINISH
CHANNE
L
NOT FINSH/
FINISH
CHANNE
L
NOT FINSH/
FINISH
PC Communication
BAUD RATE PORT ADDRESS
Profibus Address
PROFIBUS ADDRESS: _______
Shutter Trigger Setup
NPN / PNP
Digital Configuration
MACHINE CONTACT: N.O. / N.C.
FUNCTION RELAY 1: STOP / SYSTEM READY
FUNCTION RELAY 2: ALARM / ZERO SPEED
