4: Installing The Motherboard
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
User’s Manual
4•15
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Module Installation:
All modules insert in the
RIMM sockets in the same
way. The socket retaining
arms should engage the
retaining notches on the
module securely.
Make sure the module is correctly oriented
before inserting it in the socket
Retaining arms
Retaining notches
