Connecting External System Peripherals
To complete the assembly of functioning system you will
need at minimum to connect the following external sys-
tem components to the system housing:
• Video Display Monitor
• Keyboard
• Mouse or other Pointing Device
Connecting a Display Monitor
You can connect any display monitor supported by the
AGP display card you installed in the system. This may
include either a CRT or LCD monitor, depending on the
card’s specifications.
Connect the display monitor cable to the appropriate dis-
play connector on the AGP card according to the instruc-
tions that come with the card and monitor.
Connecting a Keyboard & Mouse
You can use either PS/2 or USB input devices with this
motherboard.
Connecting PS/2 Devices
Connect a PS/2 keyboard and mouse to the Keyboard
and Mouse PS/2 ports on the rear I/O port panel. Don’t
connect or disconnect a device while the system is turned
on. Doing so can damage the board.
Connecting USB Devices
You can use a USB keyboard and mouse with this
motherboard. They plug into two of the USB ports. The
Operating System you use must support USB to use any
USB devices. If your OS can operate in DOS mode, you
should enable USB Legacy Support in the Integrated Pe-
ripherals section of the CMOS Setup Utility. You can plug
and unplug USB devices when the system is turned on.
