DP400 Motherboard
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
User’s Manual
4•14
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Installing Memory Modules
Installing RIMM or CRIMM modules is simple. The mod-
ules insert in the sockets and are held in place by the
socket retaining arms. The edge connectors on the mod-
ules are of different widths and there are key notches in
the center of each module. These ensure that you can not
insert a module incorrectly.
Before you install any modules, you should review the
configuration requirements and choose a configuration.
You should then prepare the required number of RIMM
and CRIMM modules.
To install either type of module follow this procedure:
1. Align the module to the socket so that the edge
connectors on the module match the socket sections.
2. Hold the module perpendicular to the motherboard
and press the edge connector into the socket.
3. Press the module fully into the socket so that the
socket retaining arms swing up and engage the re-
tention notches at each end of the module.
Following the configuration pattern you have chosen,
repeat this procedure until all modules are installed. Re-
check the configuration pattern guide and confirm that
you have installed module in the correct configuration.
Once all modules are installed, system memory installa-
tion is complete.
System Memory Recognition
The BIOS will automatically recognize the installed
memory configuration and configure the CMOS Setup
Utility. No other action is required to complete system
memory installation.
