92
07610-003-60-98-L
SCHEMATICS
EXHAUST FAN
A1
Y1 A2
15
T
18
RED/BLK
RED/YEL
TO R10-6 (66)
GRY
BLU/BLK
WHT
TO TB2
LEGEND
T
TB
TERMINAL BOARD
TIMER
GAS CONVEYOR EXHAUST FAN HOOKUP
9905-003-14-58a
TO R8-6 (44)
TO R14-6 (86)
TO R10-9 (66)
TO R8-9 (44)
TO R14-9 (86)
TO TB2
GRY
TB
L1 L2
CUSTOMER PROVIDED
FAN CONTACTOR COIL
CUSTOMER SUPPLIED
VOLTAGE
(MAX. 250V)
