Jackson AJX Series Installation, Operation And Service Manual

32
07610-003-60-98-L
OPERATION
OPERATING INSTRUCTIONS
1. Disconnect/turn o󰀨 chemical feeder equipment.
2. Turn the machine on.
3. Add deliming solution according to chemical supplier’s instructions.
4. Close door.
5. Flip AUTOMATIC/DELIME switch to DELIME.
6. Run the machine period of time recommended by chemical supplier.
7. Wait ve minutes, then inspect inside of the machine. If the machine is not delimed,
run again.
8. Flip AUTOMATIC/DELIME switch to AUTOMATIC.
9. Run an empty rack through the machine twice.
10. Drain and re-ll the machine.
11. Reconnect/turn on chemical feeder equipment.
CAUTION! This equipment is not recommended for use with deionized water or other
aggressive uids. Use of deionized water or other aggressive uids will result in corrosion
and failure of materials and components. Use of deionized water or other aggressive uids
will void the manufacturer’s warranty.
DELIMING
!
CAUTION
100
110
120
130
140
150
160
170
180
190
200
210
220
100
110
120
130
140
150
160
170
180
190
200
210
220
100
110
120
130
140
150
160
170
180
190
200
210
220
L1
L2
L3
1
GRND
TB3
TB2
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
WASH RELAY
LINE VOLTAGE
DET L2 DET L1
CONVEYOR RELAY
LINE VOLTAGE
CVS L2 CVS L1
AU
T
O
M
AT
I
C
M
A
N
UA
L/D
E
L
I
M
E
