Jackson AJX Series Installation, Operation And Service Manual

40
07610-003-60-98-L
PARTS
AJX-66/76/80/90 CONTROL BOX
100
110
120
130
140
150
160
170
180
190
200
210
220
100
110
120
130
140
150
160
170
180
190
200
210
220
100
110
120
130
140
150
160
170
180
190
200
210
220
L1
L2
L3
1
GRND
TB3
TB2
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
1
4
7
A
3
6
9
B
4 21 23
25 24
14
9
3
2
10 10 5 11 22 1719 18 16 15 8
1
7
12
13
20
6
ITEM QTY DESCRIPTION PART NUMBER
1 1 Electrical Box 05700-041-88-50
2 1 Decal, L1, L2, L3 09905-101-12-66
3 1 Terminal Block 05940-011-48-27
4 1 Terminal Board 05940-021-89-41
5 1 Decal, Gauge 09905-021-72-30
6 1 Light, Amber (CE Only) 05945-111-44-44
7 1 Wire Lug, 2 AWG to 14 AWG 05940-200-76-00
8 1 Light, Red 05945-111-44-45
9 1 Din Rail 05700-021-72-75
10 2
Rinse Thermometer, 96” Lead
Rinse Decal, 180 °F
06685-111-68-48
09905-002-97-62
11 1
Wash, Thermometer, 48” Lead
Wash Decal, 160 °F
06685-111-68-49
09905-003-00-69
12 1 Decal, Ground 09905-011-86-86
