07610-003-60-98-L
69
1
2
3
4
5
7
6
PARTS
PAWL BAR ROLLER BRACKET
ITEM QTY DESCRIPTION PART NUMBER
1 1 Pawl Bar Bracket (No Tabs) 05700-031-92-36
2 1 Pawl Bar Roller Replacement Kit
1
06401-003-11-80
3 1 Pawl Bar Bracket (Tabs) 05700-031-84-68
4
1
1
Top Guide Block
Guide Block Replacement Kit
2
05700-011-69-49
06401-003-10-15
5 1 Pawl Bar Gutter Gasket 05330-011-68-55
6 1 Bottom Guide Block 05700-011-69-50
7 1 Pawl Bar Gutter Replacement Kit
3
05700-021-74-94
1
Kit contains the roller, roller shaft, and hardware.
2
Kit contains the top guide block, bottom guide block, and gasket.
3
Kit contains the weldment, gasket, and hardware.
When replacing one guide block, the other guide block and the gasket should be replaced as well.
