07610-003-60-98-L
63
PARTS
LOWER WASH ARM
ITEM QTY DESCRIPTION PART NUMBER
1
1
1
Lower Wash Arm Manifold, 50 Hz Machines
Lower Wash Arm Manifold, 60 Hz Machines
05700-002-24-87
05700-031-67-29
2
6
6
End-cap
End-cap Replacement Kit*
05700-011-67-11
06401-003-10-19*
3 1 Manifold Quick-Release Key 05700-011-94-45
4 6 Lanyard 05340-011-72-46
5 6 Mounting Screw, End-cap, 10-32 x 3/8" 05305-173-12-00
1
2
3
4
Complete Lower Wash Arm Assembly, 50 Hz Machines
05700-002-24-86
Complete Lower Wash Arm Assembly, 60 Hz Machines
05700-031-74-66
When replacing the screws in the end-caps, use a thread-locking product to ensure the mounting screws do not
come loose during operation.
*Kit includes the end-cap, lanyard, and mounting screw.
5
