52
07610-003-60-98-L
PARTS
RINSE INLET PLUMBING
ITEM QTY DESCRIPTION PART NUMBER
1 2 Plug, 1/8”, Brass 04730-209-07-37
2
1
1
Rinse Injector
Gasket, Rinse Injector
05700-002-03-42
05330-111-42-81
3 2 Vacuum Breaker, 1/2” 04820-003-06-13
4 6 Adapter, 1/2” 04730-011-59-53
5 3 Elbow, 1/2” 04730-406-01-01
6 2 Valve, Solenoid, 1/2” 04810-100-12-18
7 4 Union, 1/2” 04730-412-05-01
8 1 Tube, Copper, 1/2” x 2” See note below.
9 1 Tee, Copper, 1/2” 04730-411-01-01
10 1 Tube, Copper, 1/2” x 3.06” See note below.
11 1 Tube, Copper, 1/2” x 2.08” See note below.
12 1 Tube, Copper, 1/2” x 4” See note below.
13 1 Tube, Copper, 1/2” x 5.27” See note below.
14 2 Tee, 1/2” x 1/2” x 1/4” 04730-411-25-01
15
1
1
Gauge, Pressure, 0-100 PSI
Decal, 15-25 PSI
06685-111-88-34
09905-002-97-74
16 1 Valve, Ball, 1/4” 04810-011-72-67
17 1 Tube, Copper, 1/2” x 4.185” See note below.
18 1 Plug, 1/4”, Brass 04730-209-01-00
19 1 Tube, Copper, 1/2” x 5.92” See note below.
20 1 Plate, Rinse Plumbing 05700-011-82-86
21 2 Gasket 05330-111-42-81
22 1 Elbow, 90-degree, 1/2” 04730-406-32-01
23 2 Adapter, Male 04730-401-03-01
24 1 Tube, Copper, 1/2” x 5.75” See note below.
25 1 Tube, Copper, 1/2” x 4.75” See note below.
26 1 Tube, Copper, 1/2” x 40” See note below.
27 1 Plate, Deector 05700-002-62-49
Copper tubing should be purchased locally and cut to the length shown in the part description.
NOTICE
