SPECIFICATIONS AND GENERAL INFORMATION
4181384 First Edition 2-5
2
TR-3
See Figures 2-5 and 2-6.
!
CAUTION
Figure 2-5: Component Location—Right Side
Become familiar with operator controls, machine
components, and correct operating procedures
before beginning repair procedures.
1 Canopy (Optional) 8 Right Front Cutting Unit
2 OPS (Optional) 9 Right Front Wheel Motor
3 Seat 10 Front Wheel (2)
4 Steering Wheel and Tower 11 Hydraulic Oil Tank
5 Traction Pedal 12 Rear Wheel
6 Work Lights (Optional) 13 Muffler
7 Left Front Cutting Unit
2
3
4
7
TN0988
1
8
10
11
6
13
5
9
12
