Janam XT2 - Janam XT2 Specifications; Technical Specifications; Interface and Capture Features; Wireless and Mobile Features

Specifications XT2 User Manual
Janam Technologies LLC Version 3, April 2017 Specifications 14—1
Janam XT2 Specifications
14
TECHNICAL
Operating System Android 5.1 Lollipop
Processor Quad-core Qualcomm MSM8916 CPU @1.2GHz
Memory 1GB/8GB (WLAN) or 2GB/16GB (WWAN)
Expansion User-accessible microSD card slot with SD and SDHC support
Power 3000mAh rechargeable Li-ion battery (4000mAh optional)
PHYSICAL
Dimensions 6.1” L x 3.2” W x .9” D / 155mm L x 83mm W x 24mm D
Weight 9.8oz / 279g including battery; 10oz / 293g including battery and MSR
Display 5.0” High Definition (720x1280) WXGA with Corning Gorilla Glass 3;
exceptionally bright, outdoor viewable; anti-raindrop
Touch Panel Capacitive touch screen
ENVIRONMENTAL
Operating Temperature -4º to 140º F / -20º to 60º C
Storage Temperature -40º to 158º F / -40º to 70º C
Humidity Non-condensing, 95%
Drop Multiple 5ft / 1.5m drops to concrete on all sides across a wide
temperature range per MIL-STD 810G
Water & Dust IP67
Electro Static Discharge (ESD) +/- 15kV air; +/- 8kV contact
INTERFACE FEATURES
Audio 3.5mm headset jack; speaker; microphone
Alerts Vibration; LED indicators
Connectors USB 2.0
LED Indicators two dual-color LED indicators
External Buttons 4 hard keys (home; menu; back button; user-programmable)
DATA CAPTURE
Imager Zebra SE4710 1D/2D imager
Magnetic Stripe Reader ANSI/ISO-7813 full track; AES-128 CBC mode; DUKPT support
RFID/NFC Reads ISO14443 Type A; ISO14443 Type B; MIFARE UltraLight; MIFARE UltraLight C;
MIFARE 1k/4k/Plus; MIFARE DESFire;MIFARE DESFire EV1; NFC in the 13.56 MH range
WIRELESS COMMUNICATION
WWAN EDGE/GPRS/GSM; WCDMA; LTE
WLAN Dual-band 802.11a/b/g/n; Cisco certified
Security Authentication: EAP (TLS, PEAP-MSCHAPv2, PEAP-GTC, PEAP-TLS, TTLS, EAP-FAST,
LEAP)Encryption: WPA2; WPA (TKIP); WEP
WPAN Bluetooth v4.0
MOBILE APPURTENANCES
Motion Sensor Gyroscope; Accelerometer; Ambient light sensor; Proximity sensor
GPS Qualcomm® IZat™: Gen 8 support for three bands concurrently (GPS,
BeiDou and GLONASS or Galileo)
Camera 8.0MP color rear-facing autofocus camera with user-controllable LED flash
and 2.0MP front-facing camera
ACCESSORIES Single-slot cradle kit (Charging; USB), Four-slot charging cradle kit, USB Syncing/
charging cable with locking screws, Charging adapter, Extended battery kit, Holster
SAFETY/REGULATORY
Safety CSA C22.2 No.60950-1-03; EMC; RF; SAR; LED
Radio FCC; IC; GCF & PTCRB; CE
Environment RoHS and WEEE compliant
