107
UMG 509
Supply voltage
Installations of overvoltage category III
Protection of the supply voltage (fuse) 6A, type C (approved i.a.w. UL/IEC)
230 V option:
- Nominal range
- Operating range
- Power consumption
95V to 240V (45-65Hz) or DC 80V .. 300V
+-10% of nominal range
max. 7W / 14VA
Terminal connection capacity (supply voltage)
Connectable conductors. Only one conductor can be connected per terminal!
Single core, multi-core, fine-stranded 0.2 - 2.5mm
2
, AWG 24 - 12
Terminal pins, core end sheath 0.25 - 2.5mm
2
Tightening torque 0.5 - 0.6Nm
Stripping length 7mm
Current measurement
Rated current 5A
Resolution 0.1mA
Metering range 0.001 to 7 Arms
Measurement range exceeded (overload) From 7 Arms
Crest factor 2.4
Overvoltage category 300V CAT III
Measurement surge voltage 4kV
Power consumption approx. 0.2 VA (Ri=5mOhm)
Overload for 1 sec. 120A (sinusoidal)
Sampling rate 20kHz / phase
