2
UMG 509
Operation 47
Meaning of the keys 47
Measured value display 48
"Home" measured value display 49
Selecting a measured value display 50
View additional information 51
Deleting min./max. values individually 52
Transients list 53
Event list 54
Configuration 55
Connecting the supply voltage 55
Configuration menu 56
Language 56
Communication 57
Measurement 59
Measuring transducer 60
Transients 66
Events 68
Mains frequency 70
Temperature 71
System 72
Password 73
Reset 74
Display 77
Extensions 80
Commissioning the unit 82
Connecting the supply voltage 82
Connecting the measured voltage 82
Frequency measurement 83
Direction of the rotating field 83
Applying the measuring-circuit voltage 84
Table of contents
General information 4
Inspection on receipt 7
Scope of delivery UMG 509 8
Available accessories 8
Product description 9
Proper use 9
UMG 509 features 10
Measuring process 11
Operating concept 11
GridVis network analysis software 11
Connection variants 12
Installation 13
Position of installation 13
Mounting position 13
Front panel section 13
Ethernet 14
Mounting 14
Installation 16
Ground wire connection 16
Supply voltage 16
Voltage measurement 18
Three-phase 3-conductor systems 18
Rated voltages 19
Current measurement 28
Residual current measurement inputs (RCM) 32
Thermistor input 35
RS485 interface 36
Profibus interface 40
Ethernet interface 42
Digital outputs 43
