janitza UMG 509 User Manual

55
UMG 509
Configuration
The supply voltage must be connected for
the configuration of the UMG 509.
Connecting the supply voltage
• The supply voltage level for the UMG 509 is specified
on the rating plate.
• After connecting the supply voltage, a start display
appears. Approximately ten seconds later, the UMG
509 switches to the first "Home" measured value
display.
• If no display appears, check whether the applied
supply voltage is within the rated voltage range.
Please note!
If the supply voltage does not correspond
to the voltage indicated on the rating
plate, this may lead to malfunctions
and severe damage to the device.
c
Fig. Example of the "Home" measured
value display
