12
UMG 509
Connection variants
Connection of a UMG 509 to a PC via an interface
converter:
Connection of a UMG 96RM via a UMG 509 as a gateway
(gedrehtes Patchkabel)
UMG 509
Direct connection of a UMG 509 to a PC via Ethernet.
Connection of a UMG 509 to a PC via Ethernet.
(gedrehtes Patchkabel)
UMG 96RM
UMG 96RM
UMG 509
(gedrehtes Patchkabel)
UMG 509
(gedrehtes Patchkabel)
UMG 509
Switch
