UMG 509
Scope of delivery UMG 509
Number Part no. Label
1 52.26.xxx
1)
UMG 509
1 33.03.194 Operation manual
1 51.00.116 CD with following content
- GridVis programming software
- GridVis functional description
- UMG 509, GSD file "U5090F15.GSD"
1 10.01.855 Screw-type terminal, pluggable, 2-pole (auxilliary power)
1 10.01.847 Screw-type terminal, pluggable, 5-pole (voltage measurement 1-4)
1 10.01.853 Screw-type terminal, pluggable, 8-pole (current measurement 1-4)
1 10.01.873 Screw-type terminal, pluggable, 6-pole (digital inputs/outputs)
1 10.01.888 Screw-type terminal, pluggable, 7-pole (RCM, thermistor input)
1 10.01.859 Screw-type terminal, pluggable, 3-pole (RS 485)
1 08.01.505 Patch cable 2 m, twisted, grey (connection UMG PC/switch)
1 52.19.301 Mounting clips
Available accessories
Part no. Label
21.01.102 Lithium battery CR2450, 3V (approval according to i.a.w. UL 1642)
13.10.539 Profibus connector, 9-pole, D-SUB
13.10.543 Profibus connector, 9-pole, D-SUB, angled
29.01.903 Seal, 144 x 144
1)
For the item number, see delivery note
