34
UMG 509
L1 L2 L3 N I1 I2 I3
L1
L2
L3
PEN
N
PE
UMG 509
M
3~
I5
I6
I4
Residual
current
transformers
Residual current
transformer
Fig. Example UMG 509 with residual current monitoring via measuring inputs I5/I6.
Connection example, residual current monitoring
