UMG 509
Pulse output
The digital outputs can be used for the output
of pulses for the computation of power consumption.
For this purpose, a pulse of defined length is applied
on the output after reaching a certain, adjustable amount
of power.
You need to make various adjustments
in the configuration menu using the GridVis software
to use a digital output as a pulse out.
• Digital output,
• Measured value selection,
• Pulse length,
• Pulse value.
Fig.: GridVis software, configuration menu
