Jasco CD-1595 - Changing RANGE

4-6
4.2.3
Changing RANGE
RANGE setting attenuates the output to recorder so that 10mV full scale
corresponds to the RANGE parameter value.
Input range: CD RANGE: 0.0005
〜
1.28 deg, S (Short)
UV RANGE : 0.001
〜
2.56 AU, S (Short)
(G FACTOR: 1E-5
〜
2.56E-2, S (Short))
CDRANGE:0.0001
AURANGE:0.0001
Monitorscreen
NORM291X10
0.0000.000STD
[SHIFT][3]
CD RANGE
inputscreen
Blinking
[EDIT/ENTER]
CDRANGE:0.0001
AURANGE:0.0001
UV RANGE
inputscreen
CDRANGE:0.0001
AURANGE:0.0001
[EDIT/ENTER]
[MONIT]
RANGE
inputscreen
[ ][ ][EDIT/ENTER]
▲
▼
[ ][ ]
▲
▼
Figure 4.5 Changing RANGE
Note: The value ”RANGE” can be changed also with numeric kyes.
Note: AU output can be changeable to g factor output by the key operations.
( See
「
5.6 Selecting Recorder Output Mode
」
)
