Jasco CD-1595 - Setting Integrator Output Zero Level

5-6
Integrator
output
Integratoroutofrange
0V
‑10mV
Zeroshift
0V
Zeroshift
Integrator
output
Dataprocessing
asanegativepeak
0 mV
+50 mV
Figure 5.8 Negative peak vs. integrator dynamic range .
5.7.1
Setting integrator output zero level
0,5,10,30,50,100,500,1000mV can be selectable as the integrator output zero
level.
A.ZPOSITION
(INTOUT)50mV
A.ZPOSITION
50mV
Blinking
[SHIFT] [5]
Monitor screen
Settingintegratoroutputzerolevel
[EDIT/ENTER]
[ ][ ][EDIT/ENTER]
▲
▼
NORM291x10
0.00000.000STD
[MONITOR]
Figure 5.9 Setting integrator output zero level.
