4. Installation and start-up
The machine is prepared for either direct connection to a
mainswatersupplyormanuallylledviathebuilt-inwa-
ter tank. At rststart-up or after the machine has been
switched offforalongperiodoftime,themachinewillrst
attempt to take in water via the mains water inlet valve (7) for
approx. 40 seconds. If this is unsuccessful, then the pump
from the built-in water tank will start.
4.1Installationandstart-up,directconnectiontoamainswatersupply
Connect the machine from its inlet valve (7)
to a mains water supply, using the enclosed
hose (connection dimension 1/2” - 3/4”).
Connect the enclosed cable with plug to a
protective earthed electrical socket,
230VAC/50Hz. Connect the other connection
to the switched socket on the back of
the machine. Then ensure that the switch (3)
on the back of the machine is in the “On”
position “1”.
Check that the red LED (1) is illuminated with
axedredlight.Themachineheatertankis
 lledwithwaterandheatingbegins.
After approx. 5 minutes the red LED (1)
should extinguish and the green LED (2)
shouldshinewithaxedgreenlight.The
machine has then heated the water to
a pre-set temperature.
1.
2.
3.
4.
Keep in mind that the heater tank contains
hot water, which can cause scalding.
