4.2Installationandstart-up,builtinmanualllwatertank
Open then lift the front of the machine and
pushitbackwards.Removethebluellcap
marked “Water”. Fill with approx. 5 litres of
coldwater.Replacethebluellcapandclose
the front of the machine.
Connect the enclosed cable with plug to a
protective earthed electrical socket,
230VAC/50Hz. Connect the other connection
to the switched socket on the back of
the machine. Then ensure that the switch (3)
on the back of the machine is in the “On”
position “1”.
Check that the red LED (1) is illuminated with
axedredlight.Themachineheatertankis
lledwithwaterandheatingbegins.Therst
llfromthemanuallltanktakesapprox.
1 minute.
After approx. 5 minutes the red LED (1)
should extinguish and the green LED (2)
shouldshinewithaxedgreenlight.The
machine has then heated the water to
a pre-set temperature.
1.
2.
3.
4.
4.3 Installation of drink cartridges
Begin by removing the cartridge packaging. Then remove the cartridge bracket as
pergures7to9.Thispartofthecartridgeis not used in this vending machine.
Note: Never remove the rubber band.
Figure 7 Figure 8 Figure 9
