Jede QUATTRO - Description of the Front of the Machine

QUATTRO
Rev. A 2012-09-10 Service manual
6
1
2
3
4
5
6
3.5 Description of the front of the machine
1. Red LED, indicates start-up and error status.
2. Green LED, indicates normal function.
3. Lift open front.
4. Menu label.
5. Button for drink selection.
6. Spill tray.
Figure 3
