Jede QUATTRO - Description of the Inside of the Machine

QUATTRO
Rev. A 2012-09-10 Service manual
8
1
2
3
4
5
6
7
8
11
9
10
3.7 Description of the inside of the machine
Front (open position).
Drink cartridge.
Push buttons.
Funnel.
Button for rinsing.
Filling, manual tank.
Outlet nozzle.
Spill tray.
Slide, drink cartridge.
Place for drink cartridges.
Mixing bowl and steam trap.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Figure 5
