7.12 Replacing the inlet valve
Shut off the water supply to the
machine and empty the water
heater tank and the cold water
tank.
Remove the upper/lower casings
and front.
Loosen the inlet valve’s cables
(1,gure40).
Loosenthehoseforllingthe
water heater tank (2).
Loosenthehoseforoverll
protection/drainage (3).
Remove the valve by loosening
itstwoscrews(4,gure41)
from the back side of the
machine.
Mount the inlet valve in reverse
order.
1.
2.
3.
4.
5.
6.
7.
Figure 40
Figure 41
2
3
1
4
Prior to beginning service, the
machine’splugmustalways
beremovedfromthewall
socket.
