Ensure that the marking dot on the whipper
isalignedwiththeatedgeonthewhipper
shaft.(gure19),thenpressrmlyuntilit
clips fully in place.
6.5 Disassembling the machine’s internal parts
Open then lift the front of the machine and push it
backward.
Remove the drink cartridges. Note their placement.
Removethetwofunnels(2,gure16)bypulling
them straight out.
Removethedispenser(gure17)bypressinginthe
catch (1), then lift the dispenser upward and then
straight out (2).
Removethehoses(8,gure16)frommixerbowls
 (7,gure16).
Remove the mixer bowls by turning the lock ring
 counterclockwise(gure18).
Removethewhipper(12,gure16)bypullingit
outward.
Removethelockring(gure18)byturningitcoun
ter clockwise to stop and then pull it outward parallel
to the whipper shaft.
Pulloutthefanduct(3,5,gure16)andopenits
 twohalves.Removethelter(4).
Removethespilltray(11,gure16)anditsgrate
(10).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Figure 17
Figure 18
Wash all of the parts in warm water. Be careful to dry all the parts before they
are re-mounted as moisture has a negative effect on the machine’s function. Put
the parts back together in reverse order as per the above.
Figure 19
