3.6 Description of the back of the machine
1. Power switch.
2. Electrical supply.
3. Drain for manual tank.
4. Drain for heater tank.
5. Fan for ventilation.
6.Drainforoverllprotection.
7. Inlet valve (for connection to mains water supply).
Figure 4
