QUATTRO
Rev. A 2012-09-10Service manual
1
Contents
1. Important information 3
1.1 Safety 3
1.2 This user instruction 4
1.3 Type plate 4
1.4 Disposal 4
2. Symbols 4
3. Description of the machine 5
3.1 Quattro 5
3.2 Cartridge system 5
3.3 Drinks 5
3.4 Serving 5
3.5 Description of the front of the machine 6
3.6 Description of the back of the machine 7
3.7 Description of the inside of the machine 8
3.8 Placement of the vending machine 9
4. Installation and start-up 10
4.1 Installation and start-up, direct connection
to a mains water supply 10
4.2 Installation and start-up, built in manual
llwatertank 11
4.3 Installation of drink cartridges 11
5. Loading schedule 12
5.1 Loading schedule, variants 13
5.2 Change of loading schedule 14
5.3 Menu panel 14
6. Daily care and cleaning 15
6.1 Rinsing the mixer bowls 15
6.2 Cleaning the spill tray 15
6.3 External cleaning 15
6.4 Cleaning of the machine’s internal parts 16
6.5 Disassembling the machine’s internal parts 17
6.6 De-scaling 18
7. Troubleshooting 19
7.1 Resetting errors 20
7.2 Error indicators 20
7.3 Resettingoverllprotection 20
7.4 Resetting overheating protection 21
7.5 Removal of casing 22
7.6 Replacing the pump (built-in cold water tank) 23
7.7 Replacing the whipper motor 23
7.8 Replacing the dispenser motor 24
7.9 Replacing the valve unit 25
7.10 Replacing the level sensor 25
7.11 Replacing the temperature sensor 26
7.12 Replacing the inlet valve 27
7.13 Replacing the push button panel 28
