QUATTRO
Rev. A 2012-09-10 Service manual
42
Position Part number Term Quantity
1 Heater tank complete unit 1
2 36773 Divider chassis 1
3 36799 Speed nut 4
4 36710-5 PCB TM 4 1
5 Screw ST 3,5 x 13 6
6 Nut M6 1
7 36707 Transformer 1
8 Screw M3 x 12 2
9 47291 Powerentrywithlter 1
10 45030 Y-Pipe 1
11 36277 Fan duct 1
12 36705 Drain pipe 1
13 46253 Ventil, inlopp 1
14 43095 Fan 24 V DC 1
15 36706 Nippleoverow 1
16 36345 Plastic rivet 4
17 36817 Plug drain pipe 2
18 Bolt M6 x 50 1
* 36831 Cable 230 VAC 1
* 36802 RS 485 cable 1
* 36793 Fan cable 1
* 36568 Hose inlet 580 mm. 1
* 47305 Mains cable 230 V AC. 1
18 Tank module
*Cablesandhosesarenotillustratedondrawing. Recommended spare parts
