QUATTRO
Rev. A 2012-09-10 Service manual
46
Position Part number Term Quantity
1 Motor unit 1
2 36771 Serving module 1
3 36782 Button keypad 1
4 JM Dispenser 2
5 Washer NB FZB 4 x 16 x 1 2
6 Screw MRT-TT M4 x 10 2
7 36786 Funnel 2
8 36816 Airlter 1
9 36785 Fan duct 1
10 Mixer system 2
11 Screw ST 3,5 x 13 2
12 43978 Adaptor 3
13 36573 Outlet pipe, brown 1
14 36287 Holder outlet pipe 1
15 36574 Outlet pipe, black 2
16 36744 Adaptor pipe 1
* 36791 Cable serving modul 1
* 36797 LED cable 1
* 36798 Cable button keypad 1
* 36568 Silicone hose 2 x 90 mm. 1 x 110 mm. 1
20 Serving module
*Cablesandhosesarenotillustratedondrawing. Recommended spare parts
