Jede QUATTRO - Page 51

QUATTRO
Rev. A 2012-09-10 Service manual
50
Position Part number Term Quantity
1 36800 Dispenser motor 220 rpm. 4
2 36749 Crank 4
3 36750 Cam 4
4 Screw MRT-TT M4 x 10 8
5 42542 Micro switch 4
6 Screw MRT-TT M3 x 12 8
7 36790 Motor bracket 1
* 36791 Cable S-module 1
22 Motor unit
*Cablesandhosesarenotillustratedondrawing. Recommended spare parts
