12
2. Meaning of the pictograms
2. Meaning of the pictograms
Note
The pictograms are placed near the source of danger. They should warn the operator
of possible dangers.
In the following passage explains the meaning of the pictograms.
Always follow the meaning of the pictograms.
Damaged or lost pictograms need to be replaced.
Picto
ram Meanin
Position
order no.: 25239
VDMA-catalog
no.: 1
Carefully read
operator’s manual
before using the
machine. Observe
instructions and safety
rules when operating.
motor-machine:
Service-Center/near
motor-control-panel
PTO-machine: infeed
chute near valve
manifold
order no.: 25243
VDMA-catalog
no.: 8
Do not open or remove
safety shields while
engine is running.
Gearbox
order no.:25241
VDMA-catalog
no.: 9
Do not open or remove
safety shields while
engine is running.
in-feed conveyor
(optional)
order no.:25242
VDMA-catalog
no.: 10
Attach support before
getting into hazardous
area
near support
(optional for tilltable
container)
