2. Meaning of the pictograms
Picto
g
ram Meanin
g
Position
order no.: 25243
VDMA-catalog
no.: 15
Never reach into
rotating auger.
auger tube
(drumchipper)
order no.: 25244
VDMA-catalog
no.: 17
Keep away from
rotating machine parts.
1 per side right and
left of the infeed
chute
order no.: 25245
VDMA-catalog
no.: 20
Never put your hand
into the crushing
danger area as long as
parts may move.
folding in-feed
conveyer (optional)
order no.: 25246
VDMA-catalog
no.: 21
Do not open or remove
safety shields while
engine is running.
drive belt cover
order no.: 25247
VDMA-catalog
no.: 24
Wait until all machine
components have
completely stopped
before touching them.
ejector cap
