32
5. Operation and maintenance devices
5.4. Optional infeed controls and safety functions
5.4.1. Touch keys (optional)
Infeed controls for machines with touch keys. Schematic display, differences in design and type possible.
5.4.1.1. Safety bar
For machines with touch key the safety bar is only a safety function. The infeed stops
when the bar is pushed towards the infeed.
5.4.1.2. Red touch key
Additional to the safety bar the infeed can be stopped by using the red touch keys
located on both sides of the infeed chute. To turn on the infeed again use the green
touch key.
5.4.1.3. Green touch key
The first touch on the green touch key reverses the infeed. Touching the key again
puts the infeed to intake mode.
The first touch reverses the
infeed.
Touching the key again puts
the infeed to intake mode.
STOP
STOP
