5. Operation and maintenance devices
1
5.7. Motor machines (only for self-propelled machines)
5.7.1. Motor control
5.7.1.1. Kubota motor control
For machines that have a Kubota motor control all engine monitoring works from the
Kubota control panel.
Kubota control panel picture deviations possible
5.7.1.2. Machines with HMCflex control panel
For machines that have a HMCflex control panel all engine monitoring works from the
HMCflex control panel. See manual of the HMCflex in the appendix for further
information.
Control panel HMCflex picture deviations possible
1 coolant temperature
g
au
g
e
2 machine hour mete
r
3 batter
y
control li
g
ht
4 oil pressure control li
g
ht
5i
g
nition lock
6 preheat control li
g
ht
1 operation/fault LED
2displa
y
3 arrow ke
y
s
4i
g
nition lock with ke
y
s
5 SET-ke
y
2
3
4
5
6
1
2
3
4
5
