Connection Overview, PRO-Interface
Top view:
Battery and engine connection
Side view:
GSU/LED´s and expansion connectors
3x Status LED’s
8-pin ERNI connector,
expansion connector.
e.g. to LCU
6-pin ERNI connector,
expansion connector.
For connection of e.g.
Mini-GSU
Expansion connector GSU connector
To engine battery
Input for charging of
engine battery
Power output to engine
connects to engines
data connector
