The RUN Menu
As soon as the ECU is switched on, the Run menu is displayed.
In the lower display line, the actual engine RPM is indicated.
In the upper display line, the following selections can be monitored. Use the + / - buttons alone for selecting the
different parameters.
Value Explanation
Temp. Current EGT (Exhaust Gas Temperature).
The units, °C or °F can be selected in the LIMIT
s menu.
OffCnd
SetRpm
Last Off command (reason for shut down). See table on page 28
State Current engine state.
U-Pump Current pump voltage.
Airspeed Current Air speed (km/h) this readout is usual for function check of the speed sensor.
Note:
This re
adout is only supported
by
connected airspeed sensor
.
Set Speed Target state-air speed (km/h). This readout is for checking at the “speed control” mode the set
target state-airspeed of throttle stick.
Note: This readout is only supported by connected airs
peed sensor.
The Min/Max Menu
The Min/Max menu is used primarily for diagnostics purposes. All the following variables may be sampled manually by
pressing the Change Value/Item button on the GSU.
Value Explanation
Upump-Max
Upump
-
Min
Maximum pump voltage.
Minimum pump voltage.
MaxTemp
MinTemp
Maximum EGT.
Minimum EGT.
MaxRpm
MinRpm
Maximum engine RPM.
Minimum
engine
RPM.
MaxAirSpd
AvgAirSpd
Maximum Airspeed (*)
Average Airspeed (*)
Flight Distance Flight distance in km (*)
AvgRpm
MaxRTmp
Average-RPM
Average temperature at full throttle
AvgPump
AvgTemp
Average pump voltage
Average temperature
(*) Only by connected air speed sensor!
