6.0 BAY LAYOUT
PLEASE TAKE THE TIME TO READ THESE INSTRUCTIONS COMPLETELY.
A QUICK CHECK OF THE CONTENTS OF THE ACCESSORY BOX WOULD
ALSO DECREASE THE INSTALLATION TIME.
1. Gather the tools and materials required for the installation.
2. Select the location best suited for your lift. Outdoor Installation is Prohibited.
NOTE: In determining lift area check for the following:
Ease of driving a vehicle on and off the lift.
Overhead obstructions, low ceiling height, overhead doors, overhead heaters etc.
Floor obstructions, uneven floor in lift area, floor drains, work benches, electrical
wiring in floor, etc.
Anchor locations must be a minimum of 6" from any cracks
An outline matching the dimensions shown in Figure 2 will need to be marked on
the floor. Refer to Figure 3 for outline dimensions. Refer to General Lift
Specifications for overall lift dimensions.
Recommended minimum clearance around the lift is three (3) feet. Ensure
clearance conforms to local building and fire codes.
Recommended overhead clearance is a minimum twelve (12) foot ceiling
providing 6 feet for the maximum lift height and 6 feet for the supported vehicle.
For vehicles taller than 6 feet it is recommended that the user provides additional
overhead clearance or a shut off mechanism to stop the lift from raising the
vehicle too high.
DO NOT install the lift on asphalt or other unstable surfaces. Lift
columns are supported only by anchors in floor.
INSTALLER: PLEASE RETURN THIS BOOKLET TO LIFT OWNER/OPERATOR
AFTER COMPLETING INSTALLATION
