John Bean ALIGNMENT 44218Q - POWER TOWER ASSEMBLY

60 of 76
12.4 PARTS LIST – POWER TOWER ASSEMBLY
Item# Part # Description Qty.
1 4-1449 TOWER WELDM'T, POWER 1
4-1450 TOWER WELDM'T, SLAVE 3
2 2-3026 TOP PLATE - FLAMECUT 4
3 3-0581 SAFETY RACK WELDMENT 4
4 6-1401 FLAT WASHER 5/8" 4
5 6-0673 5/8" HEX NUT, GRADE 8 8
6 6-0625 3/8 ID WASHER REG PLT USS 8
7 6-0058 LOCK WASHER, 3/8" 8
8 6-0668 HHCS, 3/8 UNC X 1, GR.8 8
*9 6-0988_ALI-WL200C ALI DECAL, CAUTION 1
*10 6-0988_ALI-WL200S ALI DECAL, NOTICE 1
*11 6-0988_ALI-WL200W ALI DECAL, WARNING 1
*12 6-4086 WARNING DECAL, DECK LEVELLING 1
*13 6-1637 SAFETY DECAL 1
14 6-0248 Flat Washer, ½ ID SAE 8
15 6-0059 Lock Washer, 1/2" 8
16 6-0047 HEX HD BOLT, 1/2-13 X 1-3/4 LG, GR.5, PL 8
17 6-4322 JOHN BEAN RUNWAY DECAL 1
* NOTE: These part numbers are only applied to the front left (power) tower.
**NOTE: Items 9-11 come as a set, part # 6-0988.
