3.0 GENERAL SPECIFICATION
Figure 1 - General Specifications
Maximum Capacity 18,000 lb 8165 kg
Maximum Wheelbase – General Service 220” 5588 mm
Maximum Wheelbase – 2-Wheel
Alignment
203” 5156 mm
Maximum Wheelbase – 4-Wheel
Alignment
144” 3658 mm
Minimum Wheelbase – 4-Wheel Alignment 86” 2184 mm
Overall Length 303-3/8” 7706 mm
Overall Width 152-1/8" 3864 mm
Lowered Runway Height 9-1/2" 241 mm
Maximum Lifting Height (to runway
surface)
72” 1829 mm
Rise Time 70 Seconds
Ramp approach angle (no shims) 10°
Power Requirements
230VAC, 1PH., 20A, 60 Hz
Shipping Weight 5465 lb 2484 kg
Maximum Operating Pressure (Full Load): 2650 psi 183 bar
Air Supply Requirements: 90 - 120 psi 6 - 8 bar
