12.6 PARTS LIST – DECK ASSEMBLY (LEFT SIDE)
Item# Part # Description Qty.
1 4-0629 ALIGNMENT DECK WELDMENT LS 1
2 2-1355 DECK SHEAVE PIN 3
3 3-0681 HYDRAULIC CYLINDER ASSEMBLY 1
4 6-0248
Flat Washer, ½ ID SAE 3
5 6-0044 Hex HD Bolt, 1/2" x 1/2" 3
6 1-1747 CYLINDER SLING 1
7 6-0058 LOCK WASHER, 3/8" 3
8 6-0668 HHCS, 3/8 UNC X 1, GR.8 3
9 2-1432 CABLE FLANGE 1
10 6-0665 HOSE CLAMP, 4-1/2" 1
11 6-1644 HEX NUT, 1.375-12 UNF 2
12 6-0713 TERMINAL BOLT, 3/4", SHORT 2
13 6-0014 STREET TEE, 1/4" NPT M-F-F 3
14 6-0282 PLUG, 1/4 NPT, 01CP-4 3
15 6-0015 ELBOW 1/4NPT STREET 90D. 1
16 6-0710 ADAPTER, 3/8" POLY X 1/4"NPT M 2
17 6-1684 VELOCITY FUES, 8 GPM 1
18 6-0021 PLASTIC CAP, 3/8" JIC 1
19 6-1762 Capacity Decal 1
20 3-1115-3 REAR SLIP PLATE ASSEMBLY 1
21 3-0196 BEARING CAGE 1
22 6-0829 DELRIN BALL, 1/4" 225
23 3-0197 REAR SLIP PLATE 1
24 2-0637 LOCKING PIN ASSEMBLY 2
25 6-0426 FLAT WASHER 4
26 6-0295 FLAT WASHER, 5/16" I.D. 4
27 6-0069 Shoulder B
olt, 3/8 DIA. X 5/8 LG. 4
28 6-1134 SCREW, #12 X 1/2" 2
29 1-0757 NYLON THRUST WASHER 22
30 2-1377 SHEAVE ASSEMBLY 6
31 1-1697 SHEAVE SPACER 1" LG 3
32 8-0141 POLYTUBE, 1/4" 20FT
33 8-0142 POLYTUBE, 3/8" 20FT
