12.8 PARTS LIST – CROSSMEMBER ASSEMBLY
Item# Part # Description Qty.
1 4-0627 FRONT CROSSMEMBER WELDMENT 1
2 1-1744 LOCK SAFETY PIN WELDMENT 2
3 2-1424 SAFETY LOCK WELDMENT 2
4 6-0801
SHOULDER BOLT , 3/8 x 1 ½ LG. 2
5 6-0069
Shoulder Bolt, 3/8 DIA. X 5/8 LG. 2
6 1-0786 SHEAVE SPACER 4
7 1-1712 AIR CYLINDER BRACKET 2
8 6-0651 AIR CYLINDER 2
9 6-0663 INTERNAL TOOTH WASHER, 5/8" 2
10 6-0662 HEX JAM NUT, 5/8-18UNF 2
11 1-0757 NYLON THRUST WASHER 4
12 2-1377 SHEAVE ASSEMBLY 2
13 2-1356 SHEAVE PIN WELDMENT 2
14 2-1378 SAFETY SHOE WELDMENT 2
15 2-1376 SLIDER BLOCK WELDMENT 4
16 6-0058 LOCK WASHER, 3/8" 12
17 6-0668 HHCS, 3/8 UNC X 1, GR.8 10
18 6-0625 3/8 ID WASHER REG PLT USS 2
19 6-1693 HEX BOLT, 3/8-16UNC X 4.5LG 2
20 6-0034 HEX NUT, 3/8" NC 2
21 6-0115 COTTER PIN, 1/8 DIA X 2 LG 2
22 1-0766 CABLE ROLLER ASSEMBLY 2
23 1-0768 TENSION SPRING 4
24 EAM0139T01A COMPRESSION SPRING, SAFETY 2
25 6-0626 1/4" WASHER FENDER 4
26 6-1563 1/4-28 UNF LOCK NUT NYLON 2
27 6-0056 LOCK WASHER, 1/4" I.D. 4
28 6-0008 HEXHD. BOLT, 1/4-20 UNC x 1" LG. 4
29 6-0032 Hex Nut, 1/4"-20UNC 4
30 6-0709 SWIVEL ELBOW, 1/4" NYLON TUBE, 1/8" NPT 2
31 8-0141 1/4" POLYTUBE, 130" LONG 1
To Next Page
