12.2 PARTS LIST – LIFT ASSEMBLY
REPLACE WORN, DAMAGED OR BROKEN PARTS WITH PARTS APPROVED BY THE
ORIGINAL EQUIPMENT MANUFACTURER ONLY
Item# Part # Description Qty.
1 4-1457 POWER TOWER (FL) ASSY 1
2 4-0657-3 FRONT CROSSMEMBER ASS'Y 1
3 4-0656-3 DECK ASSEMBLY, LS 1
4 4-0659-3 DECK ASSEMBLY, RS 1
5 4-0658-3 REAR CROSSMEMBER ASS'Y 1
6 4-1458 POWER SLAVE ASSY 3
7 2-0998 WHEELSTOP WELDMENT 2
8 3-0680 APPRACH RAMP WELDMENT 2
9 2-3005 FRL & SAFETY RELEASE ASS'Y 1
10 6-1695 Power Pack, 208-230 V, 1 PH 1
11 2-1381 PIN WELDMENT - RAMP 2
12 2-1379 PULLEY COVER 4
13 2-0772 SLIDER BLOCK 8
14 6-1661 WHEEL CHOCK 2
15 6-1691 FLOW CONTROL 1
16 6-3623 DECAL, SAFETY RELEASE 1
17 6-4045 FOUR POST OPERATING INSTRUCTIONS 1
18 6-3031 DECAL, "UP" 1
19 6-3032 DECAL, "UP" 1
20 6-1692 HYDRAULIC HOSE ASSEMBLY 1
21 6-0337 RECOIL HOSE 2
22 6-1396 1/4" POLYTUBE, 10FT LONG 1
23 6-1400 3/8" POLYTUBE, 10FT. LONG 1
24 6-0725 7/8 ID FLAT WASHER 4
25 6-0724 Hex Nut, 7/8"-14UNF 8
26 6-0063 FLAT WASHER, 1/2" 14
27 6-1694 Hex HD. Bolt, 1/2"-13 UNC x 4 1/2" LG. 8
28 6-0059 Lock Washer, 1/2" 14
29 6-0035 NUT, 1/2-13 UNC, HEX 8
30 6-0295 FLAT WASHER, 5/16" I.D. 8
31 6-0293 HEX HEAD BOLT, 5/16-18UNC x 1" LG. 4
32 6-0674 LOCK WASHER, 5/16 I.D. 4
33 6-0294 HEX NUT, 5/16-18 UNC 4
34 6-0726 SET SCREW, 1/2-13 UNC X 1 LG 4
35 6-0045 Hex HD Bolt, 1/2"-13UNC x 1" LG 6
36 6-0738 FLAT WASHER 3/4" SAE 2
37 6-0115 COTTER PIN, 1/8 DIA X 2 LG 2
38 6-1379 3/4"x5-1/2" LG. 20
39 6-0714 HOSE GUARD 4FT
