SPREADER BARS MUST BE
WIDER THAN THE UNIT WIDTH
TO PREVENT DAMAGE
TO THE HOUSING
RIGGING INSTRUCTIONS:
FOR LIFTING AIR HANDLERS WITH LIFTING LUGS, USE SPREADER BARS AND CABLES AS
INDICATED. DO NOT USE A FORKLIFT. ALL LIFTING LUGS MUST BE USED TO AVOID DAMAGE.
SPREADER BARS MUST BE
WIDER THAN THE UNIT
WIDTH TO PREVENT
DAMAGE TO THE HOUSING.
cabinet and protruding components during a lift. The lugs are
positioned at the face of the sections to facilitate lifting the
sections at the factory for securing on truck trailers. Lifting lugs
can be relocated to sides of the individual sections to facilitate
placement on site supports. Use all lifting lugs provided. Adjust
the tension in each line for proper load distribution,
