Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
12/168
008831 en 2020.10
Introduction
1.4 Amendments to the manual
2020.10 Version 6
• New subsection: 4.8 Oil injection valve.
• Subsection 4.32 KRACHT oil pump has been revised.
• Subsection 4.33 Economiser, high-stage (optional) has been revised.
• Subsection 7.24 VSD equipment has been revised.
• Minor updates.
2020.06 Version 5
• New section added: 7.19 Alignment of compressor and motor .
• Minor updates.
2019.08 Version 4
• BPU coupling mounting procedure has been added.
• Description of new KRACHT oil pump.
• Updated unit drawings.
• Updated P&I diagrams.
• New compressor name plates.
• The ‘Storage’ section in the ‘Transport instructions’ chapter has been revised.
• Various minor corrections and changes.
2018.03 Version 3
• Name plates with EurAsian Conformity mark (EAC) have been added.
• ‘Requirements for competent persons’ section has been added.
• ‘F-gas regulation’ section has been updated.
• Noise data: Add 2 dBA to the values for 60 Hz compressors (used to be 3).
• The unsigned declaration of conformity has been removed. It can be found in the operat-
ing manuals.
• And more.
1.5 Manufacturer's information
This manual is produced by:
Johnson Controls Denmark ApS
Christian X's Vej 201
8270 Højbjerg, Denmark
Phone +45 87 36 70 00
CVR No 19 05 61 71
www.sabroe.com
Copyright © Johnson Controls Denmark
This manual must not be copied without the written permission of Johnson Controls Denmark,
and the contents must not be imparted to a third party nor be used for any unauthorised purpo-
ses. Contravention will be prosecuted.
