Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
008831 en 2020.10
143/168
Maintenance instructions
Oil separator, OHU 04136
SAB 193, SAB 233 and SAB 283
Oil separator
Oil cooler Oil filter
OHU 04136 Vahterus 3HH Vahterus 4HH 553E0015EU 553E0014EU
Litres Plates Litres Plates Litres
Single
Litres
Double *
Litres
Single
Litres
Double *
Litres
180
34 2.7 120 21
33 66 50 100
66 5.1
222 40
116 9
146 15
Table 52
* Optional
Note: Always keep approximately 25% extra oil available to refill at first start-up.
11.14 Motor
Motor lubrication
In connection with electric motors, it is absolutely essential to lubricate the bearings correctly and
use the appropriate type of grease.
Please refer to the motor manual and/or the motor name plate.
Replacing motor bearings
Please contact your local Johnson Controls service organisation.
