Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
134/168
008831 en 2020.10
Maintenance instructions
Maintenance intervals
Maintenance schedule
Hours operation (maximum)
200
1000
5000
8000
10000
15000
20000
25000
30000
35000
40000
45000
50000
55000
60000
65000
70000
75000
80000
85000
90000
95000
Change oil
As directed by oil analysis
Oil analysis
x
Every 6 months
Change filters
x x x x x x x x x x x
Clean oil strainers
x x x x x x x x x x x
Clean liquid strainers
x x x x x x x x x x x
Change coalescers (d)
x x x x x x
Check and clean suction screen
x x x x x x x x x x x x
Check alignment (e)
x x x x x x x x x x x
Check coupling (a)
x
Annually regardless of operating hours
Check electrical connections (b)
x x x x x x x x x x x x x x x x x x x x
Check sensor calibration (c)
x x x x x x x x x x x x x x x x x x x x x
Vibration analysis (f)
x
Every 6 months, more frequently if levels increase
Replace shaft seal
When leak rate exceeds 7-8 drops per minute
(a) Check bolts, shim packs, centre inserts, keys and all bolt torque.
(b) Check and torque all terminals in the processor and starter panel per the specification posted in the enclosure.
(c) Check calibration of slide valve, slide stop and pressure.
(d) Booster: 20,000 h. High-stage/air conditioning: 10,000 h. One stage: 30,000 h.
(e) Not for flange motors.
(f) Vibration measurement must be carried out continuously to obtain optimum preventive control on bearings. If not continuously controlled then every
6 months, more frequently if levels increase. Alternatively, major overhaul after maximum 30000 h.
(g) Verify tightness of bolts on suction and discharge flanges on a daily basis. See Table 48 for torque requirements.
Leak test: According to national rules or as a minimum according to EN 378-2 (Minimum annually if leak rate < 1% year)
Safety equipment: Check of safety equipment (Safety switch devices, pressure relief valve) according to national rules. Minimum requirement according
to EN 378, annual check of safety switch devices and every 5 years for pressure relief valve.
Table 49: Maintenance intervals
