Engineering manual - SAB 193-233-283 S A-frame (including ATEX)
008831 en 2020.10
79/168
Physical and connection data
Approx.
dimensions
SGC
1913
SGC
1918
SGC
2313
SGC
2317
SGC
2321
SGC
2813
SGC
2817
SGC
2821
SGC
2824
SAB
193 S
SAB
193 L
SAB
233 S
SAB
233 L
SAB
233 E
SAB
283 S
SAB
283 L
SAB
283 E
SAB
283 X
J
mm
(In.)
101.6
(4.00)
152.4
(6.00)
203.2
(8.00)
K
mm
(In.)
75.7
(2.98)
91.4
(3.60)
111.0
(4.37)
L
mm
(In.)
290.1
(11.42)
326.9
(12.87)
387.3
(15.25)
M
mm
(In.)
57.2
(2.25)
63.5
(2.50)
82.6
(3.25)
N
mm
(In.)
95.3
(3.75)
96.8
(3.81)
127.0
(5.00)
O
mm
(In.)
12.7
(0.50)
15.9
(0.63)
22.2
(0.88)
Table 14: Dimensional outline
Notes:
• 2817 is shown for illustrative purposes only. Configurations of other compressor sizes
vary slightly.
• Model 19xx - 28xx has an integrated suction strainer with side access on left or right.
Refrigeration suction side
On the compressor suction side, the pipe connection is made to the stop valve, pos. 101, see pip-
ing diagrams. The pipe connection is welded on the valve connecting branch.
Note: Be careful not to damage the valve and other parts of the unit when welding. See chapter
7. Installation instructions.
Refrigerant discharge side
On the compressor discharge side, the pipe connection is made to the stop valve, pos. 102, on
the oil separator, see piping diagrams. The pipe connection is welded on the connecting branch of
the valve.
Note: Be careful not to damage the valve and other parts of the unit when welding. See chapter
7. Installation instructions.
