Johnson Controls IFI-WS User Manual

Product Overview IP Requirements
12 IFI-WS Installation and Operation Manual – P/N LS10050-000JC-E:A 12/11/2014
1.6 IP Requirements
1.6.1 IP Port Settings
The following IP ports must be available to the IFI-WS:
1.6.2 Bandwidth Usage
The worst-case sustained bandwidth values are described below:
Table 1.2 IP Port Settings
Port Type Direction Purpose
25 TCP Out SMTP
123 UDP Both SNTP
2004 TCP N/A (Internal) Workstation Plug-in Access
2014 TCP Out Connection to DACR Gateway
2017 TCP Out Connection to NFN Gateway
2029 TCP Out Workstation Output Appliances (Signs)
4016 TCP In Database Import/Export
Table 1.3 Bandwidth Usage
Worst Case Sustained
Bandwidth
No. Gateways Bandwidth
Typical 200 3,360 Bytes/Sec
26,800 bits/Sec
0.027 Mb/Sec (Approx.)
Maximum 200
+ 50 Audio
617,580 Bytes/Sec
4,940,640 bits/sec
5 Mb/Sec (Approx.)
